Description
- Print area of 28” x 20”; up to 6” thick
- Print on a variety of substrates, including plastic, metal, wood, leather and glass
- Enclosed print area reduces dust contamination and UV exposure
- All ink channels offer Mimaki Circulation Technology
- Automated head height control
- Eco-friendly with low VOC, GREENGUARD Gold certified UV-LED inks
- Pair with our desktop 3D printer to produce jigs, molds for thermoforming or custom models
- RIP software RasterLink6 included
Specifications
| Printhead | Six on-demand piezo heads in a staggered array |
| Print Resolutions | 1,200 dpi |
| Print Speed (4 Color Mode) | up to 5.2 min / bed SqFt/Hr (5.2 min / bed m2/h) |
| Maximum Print Area | 27.9″ x 20.0″ (710 × 510 mm) |
| Maximum media width | 28.7″ (730 mm) |
| Maximum Media Thickness | up to 6.02″ (153 mm) |
| Maximum Media Weight | 22.0 lbs. (10.0 kg) |
| Ink Type | U.S. & Canada- LH-100, LUS-120, LUS-350 | Mexico, Central & South America- LH-100, LUS-120, LUS-350 |
| Interface | Ethernet 1000BASE-T, USB2.0 Hi-speed |
| Power Supply | Single-phase AC100 – 120V / AC200 – 240V |
| Power Consumption | AC100V: 1.3kW or less |
| Operational Environment | Temperature 59° – 86° F (15-30° C) Humidity: 35–65 % RH (Non condensing) |
| Dimensions (W × D × H) | 86.34″ x 61.89″ x 50.12″ (219.3 x 157.2 x 127.3 cm) |
| Weight | 698.87 lbs. (317 kg) |
| Certifications | VCCI class A, FCC class A, ETL UL 60950-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH, Energy Star |
| UV curable ink (LH-100) | Cyan | Magenta | Yellow | Black | White | Clear | Primer | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 250ml Bottle | I-LH100-C-B2-1 | I-LH100-M-B2-1 | I-LH100-Y-B2-1 | I-LH100-K-B2-1 | I-LH100-W-B2-1 | I-LH100-CL-B2-1 | ||||
| 1L Bottle | LH100-C-BA | LH100-M-BA | LH100-Y-BA | LH100-K-BA | LH100-W-BA | LH100-CL-BA |
| UV curable ink (LUS-120) | Cyan | Magenta | Yellow | Black | White | Clear | Primer | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 250ml Bottle | I-LUS12-C-B2-1 | I-LH100-M-B2-1 | I-LUS12-Y-B2-1 | I-LUS12-K-B2-1 | I-LUS12-W-B2-1 | I-LUS12-CL-B2-1 | ||||
| 1L Bottle | LUS12-C-BA | LUS12-M-BA | LUS12-Y-BA | LUS12-K-BA | LUS12-W-BA | LUS12-CL-BA |
| UV curable ink (LUS-350) | Cyan | Magenta | Yellow | Black | White | Clear | Primer | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 1L Bottle | LUS35-C-BA | LUS35-M-BA | LUS35-Y-BA | LUS35-K-BA | LUS35-W-BA | LUS35-CL-BA |
| UV Primer (PR-200) | Primer | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 250ml Bottle | PR200-Z-BA | |||||||||
| 1L Bottle | PR200-Z-BA |
